Specification

Electric Airless Sprayer

Power Requirements

395

100-120 V, 11 A, 50/60 Hz, 1 phase

220–240V, 7A, 50/60 Hz, 1 phase

490

100-120 V, 12 A, 50/60 Hz, 1 phase

220–240V, 6A, 50/60 Hz, 1 phase

495

100-120 V, 13 A, 50/60 Hz, 1 phase

220–240V, 7A, 50/60 Hz, 1 phase

595

100-120 V, 15 A, 50/60 Hz, 1 phase

220–240V, 7A, 50/60 Hz, 1 phase

Generator Minimum Wattage

395

3000 W

490

3500 W

495

3750 W

595

4000 W

Motor HP (W)

395

3/4 (560)

490

7/10 (510)

495

3/4 (560)

595

9/10 (671)

Cycles

395

185 l

490

165 l

495

165 l

595

143 l

Maximum Delivery

395

1.9 lpm

490

2.0 lpm

495

2.3 lpm

595

2.6 lpm

Maximum Tip Size

395

0.023

490

0.023

495

0.025

595

0.027

Fluid Outlet npsm

395

1/4 in

490

1/4 in

495

1/4 in

595

1/4 in

Weight: Stand Models

Ultra 395

20 kg

UltraMax II 490

19 kg

Ultra 495

20 kg

UltraMax II 495

19 kg

Ultra 595

N/A

UltraMax II 595

N/A

Weight: Lo-Boy Models

Ultra 395

29 kg

UltraMax II 490

25 kg

Ultra 495

29 kg

UltraMax II 495

25 kg

Ultra 595

31 kg

UltraMax II 595

31 kg

Weight: Hi-Boy Models

Ultra 395

30 kg

UltraMax II 490

26 kg

Ultra 495

30 kg

UltraMax II 495

26 kg

Ultra 595

33 kg

UltraMax II 595

33 kg

Height

Stand

53.3 cm

Lo-Boy

53.3 cm

Hi-Boy (Handle Down)

74.9 cm

Hi-Boy (Handle Up)

100.3 cm

Length

Stand

38.1 cm

Lo-Boy

66 cm

Hi-Boy

53.3 cm

Width

Stand

35.6 cm

Lo-Boy

52.1 cm

Hi-Boy

52.1 cm

Noise Levels

Sound Power

100 dBa*

Sound Pressure

90 dBa*

Basic Sprayer Wetted Parts

zinc-plated carbon steel, nylon, stainless steel, PTFE, acetal, chrome plating, leather, UHMWPE, aluminum, tungsten carbide
